Product

ALUMINIUM SUPERFICIAL PROCESSING

electrophoretic coating can be fully mechanized, automated, not only reduce the labor intensity, but also greatly improve the labor productivity, suitable for a large number of pipeline operations.

index-001_1
index-002
index-003
index-004
index-005
index-001_1
index-002
index-003
index-004
index-005

1, electrophoretic coating can be fully mechanized, automated, not only reduce the labor intensity, but also greatly improve the labor productivity, suitable for a large number of pipeline operations.

2, electrophoretic coating high rate of lysis in the water completely dissolved or emulsified, prepared into the bath viscosity is very low, it is easy to penetrate into the bag-like structure and the gap, especially for the special-shaped conductive material surface coating Installed.

3, the electrophoresis bath has a high conductivity, the coating ions in the electric field under the action of rapid swimming, in the coated surface is neutralized after the formation of electrical neutral wet paint film, with the wet film thickening resistance increased large, the amount of paint particles deposited gradually become smaller, thus forming a uniform and delicate coating film.

4, the use of high paint, up to 95% or even 100%. Due to the low solid content of the bath, the viscosity is small, the coating is brought out less paint, especially the application of ultrafiltration technology, the implementation of the coating process closed cycle, the paint recovery rate is high.

DETAILS

Types of Aluminium Extruded Profiles

Classification of Aluminum Profiles:
Aluminum profile is made by aluminum bars, melting extrusion and then get the different shapes of aluminium profiles. The production process of aluminum profiles is mainly including melting, extrusion, coloring.and the coloring mainly includes anodizing, electrophoresis coating, fluorocarbon spraying, powder coating, wood grain transfer and other processes.
Usually Aluminum profile is processed into casting products, forging products and foil, plate, belt, pipe, bar, profile, and then cold bending, sawing, drilling, assembly, coloring and other processes. So the main metal element of aluminum profile is aluminum, plus some alloy elements, improving the performance of aluminum profile. The general use of aluminum profile are building aluminum, foreign wood aluminum, aluminum for electrical machine components, aluminum for machinery, packaging and unloading containers, and aluminum for chemical installation.

index-006
index-007
index-008
index-004
index-009
index-006
index-007
index-008
index-004
index-009

Aluminum Classification by Use:
1. Architectural aluminum profiles: window and door profile and curtain walls profile.
2. Heatsink aluminum profile.
3. General industrial aluminum profile: it is mainly used for industrial production and manufacturing, such as automatic mechanical equipment, the framework of the cover and the customized mould according to the requirements of each company's mechanical equipment.
4. Aluminum alloy profile for rail vehicle structure: it is mainly used in the manufacturing of rail vehicle body.
5. Mounting aluminum profiles, making various aluminum alloy picture frames and using for mounting various exhibitions and decorative paintings.

The Characteristic of Aluminum Profile:
1. Corrosion Resistance:
The aluminum profile has a density of about 2.8g/cm3, the density is about a third of steel, copper or brass. Aluminum exhibits excellent corrosion resistance under most environmental conditions, including in the air, water, petrochemical and many chemical systems.
2. The Electrical conductivity:
Aluminum profiles are often used because of their excellent electrical conductivity. Aluminum conducts nearly twice as much electricity as copper under the same weight.
3. Thermal conductivity:
The thermal conductivity of aluminum alloy is about 50-60% that of copper, which is very beneficial for the manufacture of heat exchangers, evaporators, heating appliances, cooking utensils, as well as automobile cylinder heads and radiators.
4. Non-ferromagnetism:
Aluminum profiles are non-ferromagnetic, an important property for the electrical and electronic industries.
5. Machinability:
Aluminum profile machinability is very good, is better than many of the same industrial building materials.
6. Formability:
Specific tensile strength, yield strength, ductility and the corresponding workhardening rate govern the allowable deformation. Various investigations have shown that the rating of the formability of commercially available aluminum profiles in different shapes depends on the forming process.
7. Recycling:
Aluminum is highly recyclable and its properties are almost indistinguishable from those of primary aluminum.

Aluminum Profile Production Process:
Mainly including casting, extrusion and coloring (Coloring mainly includes: oxidation, electrophoresis coating, fluorocarbon spraying, powder spraying, wood grain transfer, etc.) three processes.
1. Melting is the first process of aluminum profile production
The main process:
(1) Ingredients: According to the specific alloy brand to be produced, calculate the amount of addition of various alloy components, and reasonably match various raw materials.
(2) Melting: The prepared raw materials are added into the melting furnace to melt according to the process requirements, and the impurities and gases in the melt are effectively removed by means of degassing and slag removal refining.
(3) Casting: Molten aluminum is cooled and cast into round bars of various specifications through deep well casting system under certain casting process conditions.
2. Extrusion:
Extrusion is the means of forming profiles. Firstly  according to the profile product section design, manufacture the mold, use the extruder to extrude the aluminum bar from the mold to the profile. The normally used alloy is 6063 alloy there is also an air-cooled quenching process and subsequent manual aging process during extrusion to complete the heat treatment strengthening. The heat treatment system of different grades of heat treatable alloy is different.
3. Coloring (The anodizing process is mainly discussed here)
Anodizing: the extruded aluminum alloy profile has a weak corrosion resistance on its surface. The surface treatment must be carried out through anodic oxidation to increase the corrosion resistance, wear resistance and appearance of the aluminum. High compartment aluminum plant production of high compartment aluminum is almost all oxidized.

DETAILS

ALUMINIUM PROFILE-DEEP PROCESSING

electrophoretic coating high rate of lysis in the water completely dissolved or emulsified, prepared into the bath viscosity is very low, it is easy to penetrate into the bag-like structure and the gap, especially for the special-shaped conductive material surface coating Installed.

deep-1
deep-2
deep-3
deep-4
deep-1
deep-2
deep-3
deep-4

1, electrophoretic coating can be fully mechanized, automated, not only reduce the labor intensity, but also greatly improve the labor productivity, suitable for a large number of pipeline operations.

2, electrophoretic coating high rate of lysis in the water completely dissolved or emulsified, prepared into the bath viscosity is very low, it is easy to penetrate into the bag-like structure and the gap, especially for the special-shaped conductive material surface coating Installed.

3, the electrophoresis bath has a high conductivity, the coating ions in the electric field under the action of rapid swimming, in the coated surface is neutralized after the formation of electrical neutral wet paint film, with the wet film thickening resistance increased large, the amount of paint particles deposited gradually become smaller, thus forming a uniform and delicate coating film.

4, the use of high paint, up to 95% or even 100%. Due to the low solid content of the bath, the viscosity is small, the coating is brought out less paint, especially the application of ultrafiltration technology, the implementation of the coating process closed cycle, the paint recovery rate is high.

DETAILS

Aluminum Formwork

Aluminium formwork is a construction system for forming cast in place concrete structure of a Building. ADTO Formwork system provides Aluminium formwork for RCC, load-bearing, multi-storeyed buildings and enables the walls and slab to be poured in the same operation. This increases efficiency, and also produces an extraordinarily strong structure with excellent concrete finish.

aluminium-formwork-1
aluminium-formwork-2
aluminium-formwork-3
aluminium-formwork-4
aluminium-formwork-5
aluminium-formwork-6
aluminium-formwork-7
aluminium-formwork-1
aluminium-formwork-2
aluminium-formwork-3
aluminium-formwork-4
aluminium-formwork-5
aluminium-formwork-6
aluminium-formwork-7

1. MONOLITHIC SYSTEM

Goldapple Aluminium system allows building for monolithic and /or 2 stages casting application to suit all kinds of building requirements.

2. Aluminium Panels-Extruded Sections

Our panels are all extruded sections by high pressure pressers thus giving the toughness strength required by construction need. They are mechanically linked together -not ONLY from welding

3. ALUMINIUM ALLOY 6061-T6

6061-T6 is one of the most versatile of the heat-treatable alloys, is popular for medium to high strength requirements and possesses good to toughness characteristics. 6061-T6 has excellent corrosion resistance to atmospheric conditions and good corrosion resistance to sea water.

4. ALUMINIUM PANELS WITH POWDER COATING

Goldapple PATENTED PPWDER COATED ALUMINIUM FORMWORK achieves smooth concrete surfaces, more durable and easy to clean. No rendering is needed--savings on materials and labour costs.

5. STRONG& DURABLE DETAILS

6. EARLY STRIKE

Our early strike system allows slab panels to be striped after casing within 4 days and provide top quality surface finish on the concrete, by using our special designed prop head.

DETAILS
